Product Description
TECHNICAL DESCRIPTION FIBER LASER MARKING MACHINE
Overview
The Fiber Laser Marking Machine is a high-precision, non-contact marking system designed for permanent engraving on metallic and selected non-metallic materials. It utilizes advanced fiber laser technology to deliver high-speed, high-contrast, and maintenance-free marking solutions for industrial applications.
Working Principle
The system generates a high-energy laser beam through a fiber laser source, which is directed via a galvanometer scanning system onto the workpiece surface. The intense energy creates a permanent mark by oxidation, engraving, or ablation without causing mechanical stress.
Machine Configurations / Models
- Desktop Model Compact, stable, suitable for batch production
- Portable Model Lightweight, ideal for on-site marking
- Fly (Online) Model High-speed marking for continuous production lines
- Online Marking System Integrated with conveyor/automation systems
- CO Metal Tube Marking Machine Suitable for coated metals and non-metal materials
Main Components
- Fiber Laser Source (Raycus / JPT / IPG optional)
- Galvanometer Scanner (High-speed scanning head)
- Field Lens (F-theta lens for precise marking area)
- Control System (EZCAD software-based)
- Industrial Computer / Controller
- Laser Marking Software (Windows compatible)
- Work Table / Conveyor (as per model)
- Rotary Attachment (optional for cylindrical marking)
Technical Specifications
| Parameter |
Specification |
| Laser Type |
Fiber Laser |
| Output Power |
20W / 30W / 50W / 100W |
| Wavelength |
1064 nm |
| Marking Area |
100100 mm to 300300 mm (optional) |
| Marking Speed |
Up to 7000 mm/s |
| Minimum Line Width |
0.01 mm |
| Repeat Accuracy |
0.001 mm |
| Cooling System |
Air Cooling |
| Power Supply |
220V / 50Hz |
| Power Consumption |
< 800 W |
| Supported Formats |
PLT, DXF, BMP, JPG, AI |
| Operating System |
Windows-based (EZCAD) |
Material Compatibility
Metals:
- Stainless Steel
- Mild Steel
- Aluminum
- Brass
- Copper
- Titanium
Non-Metals (Limited):
- ABS
- PVC
- Coated Materials
- Anodized Surfaces
Applications
- Serial Number Marking
- Barcode / QR Code Marking
- Logo Engraving
- Nameplate Marking
- Tool & Die Marking
- Automotive Parts Marking
- Electrical Components Marking
- Jewelry Engraving
Key Features
- High-Speed & High Precision Marking
- Permanent and Tamper-Proof Marking
- Maintenance-Free Operation
- Long Laser Life (>100,000 hours)
- Low Power Consumption
- No Consumables Required
- Compact and User-Friendly Design
- Suitable for Continuous Industrial Use
Safety Features
- Laser Safety Enclosure (optional)
- Emergency Stop Button
- Protective Laser Goggles
- Interlock Safety System
Advantages
- Non-contact process (no tool wear)
- Eco-friendly (no chemicals or inks)
- High reliability and low maintenance cost
- Suitable for automation and Industry 4.0 integration
Optional Accessories
- Rotary Device for cylindrical objects
- Conveyor System for online marking
- Fume Extractor
- Vision System (CCD Camera)
- Autofocus System
High Precision and EfficiencyThis fiber laser marking machine stands out for its remarkable repeatability accuracy of 0.001 mm and swift marking speeds of 7000 mm/s. Such precision enables even the smallest character size of 0.15 mm and finest line width of 0.01 mm, making it ideal for intricate designs or detailed industrial marks. Whether you require deep, visible engravings or subtle, fine lines, this versatile system delivers consistent results at an industrial scale.
Versatile Applications for IndustryEngineered for robust industrial environments, this system is suitable for permanent marking on electronics, machine parts, tools, and a wide range of components. It supports multiple image formats, including PLT, BMP, JPG, PDF, and more, giving users the flexibility to engrave logos, serial numbers, QR codes, or graphics directly onto surfaces with various optional marking area sizes.
User-Friendly and Reliable OperationThe computerized control system, combined with dedicated marking software and air cooling, guarantees stable and efficient performance. Intuitive controls allow operators to set precise marking parameters, ensuring optimal operation from 0C to 45C. Its compact structure and lightweight design (approx. 25-35 kg) make installation and relocation easy for a variety of industrial setups.
FAQ's of Fly Fiber Laser Marking Machine:
Q: How does the Fly Fiber Laser Marking Machine ensure precise and permanent markings?
A: The machine utilizes advanced fiber laser technology with a 1064 nm wavelength, achieving high repeatability accuracy of 0.001 mm. Its computerized control and dedicated marking software help produce sharp, durable engravings, allowing for fine line widths down to 0.01 mm and deep marks up to 1.2 mm, depending on the material.
Q: What materials and industries can benefit from this device?
A: This laser marking machine is designed for a wide range of industrial applications, including electronics, tools, automotive components, and metallic or non-metallic surfaces. Exporters, suppliers, and manufacturers can use it for permanent part identification or branding.
Q: When is it recommended to choose between 20W, 30W, or 50W laser power?
A: You should select the laser power based on your production volume and marking requirements. Lower power (20W) is sufficient for basic engraving tasks and thin materials, whereas higher powers (30W or 50W) are better for deeper or faster markings on tougher surfaces or high-throughput operations.
Q: Where can the machine be installed, and is it portable?
A: Thanks to its compact and portable design, the machine can be easily set up in various industrial workshop environments. Its lightweight structure (25-35 kg) allows for convenient relocation, and its air cooling system means no external water chiller is required.
Q: What is the typical process for marking using this fiber laser machine?
A: Operators use the computerized control system and dedicated software to load the desired image or text (supported formats include PLT, BMP, JPG, PNG, TIF, DXF, AI, SVG, etc.). Once settings are configured, the laser accurately marks or engraves the pattern onto the workpiece, ensuring uniform results.
Q: How does the system handle cooling and what are its power requirements?
A: The Fly Fiber Laser Marking Machine uses an efficient air cooling system, maintaining optimal temperature during continuous industrial operation. It is powered through a standard 220V / 50Hz supply, making it compatible with most industrial electrical setups.
Q: What are the key benefits of using this marking machine for industrial applications?
A: Key benefits include high marking speed, exceptional precision, long operational lifespan (up to 100,000 hours), flexible marking area, and broad material compatibility. Its reliability and user-friendly operation help increase productivity and product traceability for industrial users.
